Dual Laser Workstation
Integrates 1550nm non-ablative fiber & USA Synrad 10600nm RF CO2 lasers in one unit.
Korean 7-Joint Arm
360° full rotation articulated arm for high light transmittance and free multi-angle operation.
Non-Ablative & Ablative
Covers zero-downtime superficial anti-aging up to deep scar, lesion removal & gyne care.
4 Modes & Multi-Probes
Fractional, surgical cutting, gyne & vulva modes with customizable scan graphics and heads.
Advanced Dual-System Fractional Laser Technology
Our integrated dual-system aesthetic laser combines 1550nm non-ablative erbium fiber laser and USA Synrad 10600nm RF fractional CO2 laser within one workstation. Two complementary wavelengths cover shallow gentle anti-aging and deep powerful tissue remodeling simultaneously, solving all skin rejuvenation, scar repair, surgical excision and vaginal tightening demands.
1550nm erbium laser creates microscopic thermal zones without epidermal peeling, delivering low-downtime deep collagen stimulation for fine lines, pores and mild acne pits. The 10600nm RF CO2 laser provides controllable micro-ablation, ideal for deep scars, stretch marks, skin lesion removal and gynecological intimate rejuvenation.
Equipped with Korean 7-joint 360° articulated arm, German stepping scanning motor, multi-mode intelligent touch screen and interchangeable treatment probes, this all-in-one machine serves beauty therapists, dermatologists and gynecologists. Fully certified CE Medical, FDA, ISO13485 & RoHS, with full OEM private label customization support for global clinics and distributors.
How It Works
1550nm Erbium Non-Ablative Laser
1550nm near-infrared fiber laser generates tiny Micro Thermal Zones (MTZs) deep in dermis while keeping the epidermis intact. Healthy surrounding skin acts as natural repair reservoirs, speeding recovery greatly.
-
Deep Collagen Stimulation: Penetrate deep dermal layers to trigger mass regeneration of type I & III collagen;
-
Superficial Skin Refining: Treat fine wrinkles, enlarged pores, mild acne scars, dull photoaging skin;
-
Low Social Downtime: Ultra-short social downtime, minimal redness and zero obvious scabbing;
-
Flexible Operating Heads: Adjustable spot energy: 1–120mJ, 3 optional handpieces (20/30/50mm) for targeted facial & body areas.
10600nm RF Fractional CO2 Laser
10600nm CO2 features ultra-high water absorption, realizing controllable micro-ablation and precise tissue vaporization. Equipped with Fractional / Surgical Cutting / Gyne / Vulva four working modes:
-
Fractional Mode: Peel off irregular scar tissue, rebuild uneven skin texture for deep acne pits, surgical scars and stretch marks.
-
Surgical Cutting Mode: Precise excision of moles, warts, fibromas and benign epidermal lesions with excellent hemostasis.
-
Gyne & Vulva Mode: 360° rotating dedicated probe stimulates vaginal collagen contraction for tightening, dryness improvement and postpartum recovery.
Combined Dual-Wavelength Advantage: Clinicians can match two wavelengths according to mixed skin problems: use 1550nm for daily mild anti-aging maintenance, switch to CO2 for heavy scar and intimate projects. One machine covers full high-margin service lines, cutting multi-device procurement costs for clinics.
Key Advantages
Dual Independent Laser Source System
Separate 30W 1550nm erbium fiber module + 1–60W USA Synrad RF CO2 tube, freely switch single wavelength or combined treatment without energy interference.
Premium Imported Core Hardware
-
USA Synrad RF metal laser tube: Long service life, stable continuous energy output, low replacement cost.
-
Korean 7-joint full rotation articulated arm: High light transmittance, free multi-angle operation.
-
German mini stepping scanning motor: Uniform laser spot distribution, avoid uneven ablation & pigmentation.
Four Multi-Functional CO2 Working Modes
Fractional beauty mode / Surgical cutting mode / Gyne mode / Vulva mode, fully satisfy aesthetic, surgical and gynecological clinical needs. 4 built-in cutting waveforms for precise lesion removal.
Easy-Operate Intelligent Touch UI
Preset professional clinical parameter templates for wrinkles, scars, pigment and intimate care; new technicians can master operation quickly without lengthy training.
Intelligent Adjustable Parameters & Air Cooling
Customizable spot density (25–3025 PPA), pulse energy and scan range; built-in cold air cooling system to reduce treatment pain and post-treatment swelling. Two operation modes: Stamp static mode & moving dynamic mode for flexible clinical operation.
Multi-Size Interchangeable Treatment Accessories
-
3 kinds of 1550nm scan heads: 20mm (eye/lip delicate area), 30mm (forehead/nose), 50mm (full face & body).
-
Multiple customizable scan graphics: Square, circle, hexagon, triangle, rectangle, irregular shape.
-
Dedicated 45° reflector gyne handpiece: For vaginal & vulva rejuvenation.
Clinical Applications
1550nm Erbium Laser Treatments
-
Anti-Aging: Crow’s feet, forehead lines, nasolabial folds, sagging & dull photoaged skin.
-
Skin Refining: Enlarged pores, rough texture, mild acne pits & acne marks.
-
Auxiliary Therapy: Improve scalp environment to support hair regrowth.
10600nm CO2 Fractional Beauty Mode
Deep acne scars, surgical scars, stretch marks, sun spots, seborrheic keratosis, overall skin resurfacing.
10600nm CO2 Surgical Mode
Precise removal of moles, flat warts, fibroma, skin tags and other benign epidermal neoplasms.
10600nm CO2 Gyne & Vulva Mode
Vaginal tightening, postpartum vaginal recovery, improve vaginal dryness & sensitivity, vulva pigment lightening, vulva atrophy repair.
Main Advantages
-
High Equipment ROI: Two professional laser systems integrated into one device, save clinic space and huge equipment investment cost.
-
Full-Line Service Coverage: Cover light maintenance anti-aging to deep scar & gyne high-profit projects, maximize salon service revenue.
-
Balanced Customer Experience: 1550nm low downtime for social clients; CO2 powerful effect for severe skin lesions.
-
Low Maintenance Expense: Imported core parts guarantee long-term stable operation, reduce later maintenance and replacement expense.
-
Global Compliance Ready: Meet European NiSV & global medical certification standards, support local equipment filing for overseas clinic owners.
-
Low Staff Training Cost: Multiple replaceable probes and preset parameter templates lower technician training difficulty.
Technical Specifications
Specification
Detailed Parameter
Laser Type
Erbium glass fiber laser
Rated Power
30W
Adjustable Energy
1–120mJ
Spot Density
25–3025 PPA
Optional Scan Heads
20mm / 30mm / 50mm
Cooling System
Built-in air cooling
Scan Graphics
Square, Rectangle, Circle, Semicircle, Rhombus, Irregular shape
Specification
Detailed Parameter
Wavelength
10600nm RF CO2
Output Power
1–60W adjustable
Max Scan Range
20mm × 20mm
Spot Diameter
100μm – 2000μm
Working Modes
Fractional / Surgical Cutting / Gyne / Vulva
Scan Sequence
Order / Center / Random
Delivery System
7-joint 360° rotating articulated arm
